| 是否进口：否 | 产地：中国 | 品牌：BEJ |
| 型号：ST-A03 | 电源线长：依客户要求定制 | 孔位数：2个 |
| 额定电流：2.*** | 货号：ERP | 额定电压：220V |
| 环境温度：20--100℃ | 壳体材质：PBT 或 PA66 | 导电体材质：黄铜 |
| 物料编号：ERP | 产品认证：VDE,UL,CCC，Semko，Demko，Fimko,Nemko | 尺寸：国标标准 |
| 额定功率：625 | 适用范围：适配器 室内小家电 | 特色服务：可包邮 |
| 加工定制：否 | 订货号：ERP | 最小包装数：100pcs |
| 颜色：黑色 | 规格：塑胶袋包装 | 是否跨境货源：否 |
开关参数如下
SPECIFICATION
Rating | 8A 250VAC 10A 125VAC |
Initial Contact Resistance | 50mΩ max. |
Insulation resistance | 100MΩ |
Withstand voltage | 1500VAC for terminal to terminal 1 minute 3000VAC for terminal to body 1 minute |
Mechanical life | 100000 cycles |
Electrical life | 10000 cycles |
Working temperature | ≤105℃ |
Working force | 550±250gf |
Main material | Body : PA66 |
Actuator : PA66 | |
Terminals and movable contact : Brass | |
Certificates | UL. VDE,ENEC, CQC |
插座参数如下 SPECIFICATION
Rating | 2.*** 250VAC |
Standards | UL498, IEC60320,GB17465 |
Initial Contact Resistance | 20mΩ max. |
Insulation resistance | 100MΩ (min) for DC 500V |
Withstand voltage | 1500VAC for terminal to terminal 1 minute 3000VAC for terminal to body 1 minute |
Working temperature | ≤105℃ |
Main material | Housing : PA66 , PC |
Terminals : Tin-plated brass | |
Certificates | UL.CUL,CCC,VDE,SEMKO,NEMKO,FIMKO,DEMKO.SAA,EK |
满足RoHS 及 REACH要求。
